Features for MFMP-2C/MFMP-1C:
* PID & PWM controller.
* LCD touch screen for MFMP-2C/MFMP-1C.
* USB & RS232 interface.
* The melting curve can be recorded automatically.
* It can calculate average value of initial and final melting points automatically.
Features for MFMP-1B:
* Photoelectric test.
* LCD display.
* RS232 interface.
* Real time melting curve.
Technical Parameters:
Model | MFMP-2C | MFMP-1C | MFMP-1B | |
Measuring Range | RT~360℃ | RT~400℃ | RT~320℃ | |
Resolution | 0.1℃ | |||
Linear Heating-up Rate | 0.1℃ ~20℃/min | 0.2, 0.5, 1.0, 1.5, 2.0, 3.0, 4.0, 5.0℃/min | ||
Temperature Accuracy | 0.4℃ (≤200℃) 0.7℃ (>200℃) | |||
Repeatability | 0.3℃ | |||
Capillary Size | φ1.4mm (outside diameter), φ1.0mm (inside diameter), 80mm (height) | |||
Sample Loading Height | 3~5mm | >3mm | ||
Data Storage | 1000 sets | / | ||
Optional Accessories | Printer | / | Printer | |
Power Supply | AC 220V/110V±10%, 50/60Hz | |||
External Size (W*D*H) mm | 410*290*110 | 330*290*110 | 330*290*110 | |
Package Size (W*D*H) mm | 576*428*306 | 492*428*305 | 496*428*306 | |
Gross Weight (kg) | 13 | 11 |
